EDCS-8210
10 W peak power – 100 V
Two power taps (5 and 10 W)
Modern and stylish ABS design with integrated mounting clamp
Magnet detachable grille for easy installation and maintenance
Available in either black and white
The DAP EDCS-8210 is a 8-inch recessed ceiling speaker suitable for 100 V installations. The volume can be adapted to match the volume of other components in the system using the multiple power taps on the transformer. The DAP EDCS series combine a good sound quality and stylish design in an affordable solution for commercial audio installations.
The EDCS-8210 is available in both white and black enclosures and are the right tool for any installation audio job. The elegant but strong grille is held in place by powerful neodymium magnets. This makes assembly and disassembly very easy but reliable to keep the grille in place during the complete lifetime of the loudspeaker. Besides, it has a small Ø 210 mm mounting size and mounting is easy due to the integrated clamp.
Transformer: 100 V
Line Transformer Taps: 5 / 10 W
Passive Input Connection: Open End
Speaker System: Coaxial
Speaker Sensitivity (1 W/1 m): 93 dB
Speaker Impedance: 8 Ω
Maximum SPL at 1 m: 98 dB
Frequency Response Minimum: 100 Hz
Frequency Response Maximum: 15000 Hz
Woofer Diameter: 8"
Dispersion Angle (Horizontal): 360°
Dispersion Angle (Vertical): 180°
Height (mm): 88 mm
Width (mm): 232 mm
Length (mm): 232 mm
Weight: 0.9 kg
IP Rating: IP20 (indoor use only)
Mounting Size: Ø 210 mm
