HS-30S
Passive 30 W Square Horn Speaker - light gray
DAP![DAP]()
30 W peak power – 70/100 V
Five power taps (1.9–30 W)
Suitable for short throw outdoor applications (IP66)
Robust ABS housing
Bracket included
The DAP HS-30S is a light gray passive 30-watt square horn speaker suitable for public addressing. Because the horizontal spread is better than the vertical spread, it is often used for short-throw applications.
You can use the HS-30S in a 70 V/100 V installation to produce beautiful mid to high frequencies with a maximum SPL of 105 dB at 1 meter. The volume can be adapted to match the volume of other components in the system using the multiple power taps on the transformer. With an IP66 certification, it is suitable for outdoor applications. An included bracket makes for easy installation.
Peak Input Power: 30 W
Transformer: 70+100 V
Line Transformer Taps: 1.9 / 3.75 / 7.5 / 15 / 30 W
Passive Input Connection: Open End
Speaker System: Horn
Speaker Sensitivity (1 W/1 m): 105 dB
Speaker Impedance: 8 Ω
Frequency Response Minimum: 350 Hz
Frequency Response Maximum: 8000 Hz
Height (mm): 205 mm
Width (mm): 280 mm
Length (mm): 285 mm
Weight: 2.25 kg
IP Rating: IP66
Transformer: 70+100 V
Line Transformer Taps: 1.9 / 3.75 / 7.5 / 15 / 30 W
Passive Input Connection: Open End
Speaker System: Horn
Speaker Sensitivity (1 W/1 m): 105 dB
Speaker Impedance: 8 Ω
Frequency Response Minimum: 350 Hz
Frequency Response Maximum: 8000 Hz
Height (mm): 205 mm
Width (mm): 280 mm
Length (mm): 285 mm
Weight: 2.25 kg
IP Rating: IP66
