CS-620
Passive 6" Ceiling Speaker - white
DAP![DAP]()
20 W peak power – 100 V
Three power taps (5, 10 and 20 W)
Flat frequency response for a natural sound
Integrated clamps
Mounting size: Ø 225 mm
The DAP CS-620 is a passive 6-inch ceiling speaker suitable for 100 V installations. This white 20-watt recessed speaker has a flat frequency response for transmitting a natural sound. The volume can be adapted to match the volume of other components in the system using the multiple power taps on the transformer.
The CS-630 has a strong ABS housing that can be mounted easily in a Ø 225 mm hole due to its integrated clamps.
Peak Input Power: 20 W
Transformer: 100 V
Line Transformer Taps: 5 / 10 / 20 W
Passive Input Connection: Terminal
Speaker Sensitivity (1 W/1 m): 94 dB
Frequency Response Minimum: 110 Hz
Frequency Response Maximum: 15000 Hz
Woofer Diameter: 6"
Height (mm): 60 mm
Width (mm): 245 mm
Length (mm): 245 mm
Weight: 1.1 kg
IP Rating: IP20 (indoor use only)
Mounting Size: Ø 225 mm
Transformer: 100 V
Line Transformer Taps: 5 / 10 / 20 W
Passive Input Connection: Terminal
Speaker Sensitivity (1 W/1 m): 94 dB
Frequency Response Minimum: 110 Hz
Frequency Response Maximum: 15000 Hz
Woofer Diameter: 6"
Height (mm): 60 mm
Width (mm): 245 mm
Length (mm): 245 mm
Weight: 1.1 kg
IP Rating: IP20 (indoor use only)
Mounting Size: Ø 225 mm
